710 (South Korea, )

The beginning of the end

Sample: Silicon crystal structure in microchannel

Size: 10µm × 10µm

Scientific image: Park System staff

Experimental details
  • System: NX10
  • Scan Mode: Non-contact
  • Cantilever: AC160TS (k=26N/m, f=300kHz)
  • Scan Size: 3µm × 3µm, 5µm × 5µm
  • Scan Rate: 1Hz, 0.5Hz
  • Pixel: 512×256, 512×256
Get the article
